Building Product Brochures & Datasheets

Roofing

Africote Waterproofing Products

Africote Waterproofing Products Platinum Waterproofing – Dual cementitious / acrylic based waterproof coating Bitumen Aluminium – rust inhibitive coating Fibreshield – with fibre Watershield – without fibre

Clotan Craft-Lock | The Concealed Fix Profile for Roof and Facade Applications

A Craft-Lock roof sheet profile is characterised by its hidden fasteners. The use of a starter bar and fixing cleats allows positive fixing of the roof. This eliminates potential leakage problems and enhances aesthetics.

Widespan Roof Sheeting | Clotan Steel

Widespan is a roofing and cladding profile designed to provide an economic alternative to deeper Box Rib profiles without losing the aesthetic appeal of a square fluted profile. The trapezoidal Widespan profile offers greater spans and lower roof slopes than Corrugated sheeting, but provides the same covering width. Widespan can be factory cranked, curved and bullnosed to various radii depending on customers’ requirements.

Bituver | Cool Roof Solutions | Isover

Bituver Cool Roof Solutions – waterproofing – reduction of heat effect – energy saving

IBR Roof Sheeting / Side Cladding | Clotan Steel

IBR roof sheeting is a square fluted profile with an effective covering width of 686 mm, designed for use as side cladding or roofing material in commercial, industrial and residential buildings.

GRS Sungazer

The Sungazer is a revolutionary lighting product, installed in the roof, that harvests sunlight to deliver full-spectrum natural light to the inside of the building. It also provides significant electrical energy savings as electrical lights can be switched off during the day when the sun is shining. The Sungazer maintains a stationary, collimated beam of light throughout the day. The standard lens can be substituted with custom-designed lenses to provide unlimited design possibilities for architects and lighting designers.

Alchemica Building Chemicals | Hyperdesmo | Waterproofing Leadership

Alchimica Hyperdesmo liquid applied, polyurethane waterproofing membranes cure with a reaction to atmospheric humidity to form a highly elastic and extremely hydrophobic membrane with excellent mechanical as well as chemical properties. It is an ideal solution for exposed waterproofing thanks to its excellent adhesion properties.

Roof Insulation from A-Z

D&D Roof Insulations supplies roof insulation materials fit for large-format steel roof structures with steel cladding, roof sheeting, side cladding and more

WRC Projects Profile

WRC Projects Company Profile Construction, Maintenance & Turnkey

DERBIT® SP FR | The APP-Bitumen Waterproofing Membrane

DERBIT SP FR is composed of a blend made of a specific bitumen modified by noble polymers (high-grade APP also called TPO) & two distinct reinforcements, fibreglass & nonwoven polyester.

Swartland | Col Timbers | Mouldings, Par, Cornices, Awnings & Finished Products

About Col Timbers PERFECTLY ENGINEERED Wood is perfectly crafted by nature. Col has taken this one step further by engineering the timber to create products that are both sustainable and beautiful in your home. Col products are laminated with waterproof adhesive to improve strength and stability. Finger-joints allow for longer lengths of clear timber, helps to minimise lateral movement and ensures the timber retains its natural beauty over time. SUSTAINABLE RESOURCE Timber is a sustainable and renewable resource. The more wood we use, the more forests we grow. Not only does wood bring warmth into your home, but it’s also the best choice for the environment. PINE Our pine is sourced from local plantations that are FSC ®-certified. FSC® certification ensures that products come from well-managed forests that provide environmental, social and economic benefits. This aligns the vision of saving the world’s forests for future generations – Forests For All Forever ® HARDWOOD Our hardwood is sourced from sawmills internationally, where governments in these regions have implemented strict sustainability policies and compulsory harvesting programmes. These policies protect the environment and forest ecosystems as well as the interests of local communities.

Timber Decking Substructure Regulations and Preservative Treatment

This Guidance Note addresses the importance of the use of properly preservative treated timber in the  construction of substructures for timber decks and its compliance with the requirements as stipulated in the Building Regulations and relevant SANS Standards.

WeatherMaster: The Ultimate Louvre Awning

The WeatherMaster adjustable louvre awning with remote control option. The adjustable louvre awning provides shade and rain protection when closed and provides ventilation, light and sunshine when open.

WeatherMaster: The Original Adjustable Louvre Awning

The WeatherMaster adjustable louvre awning can adjust for shade or sunshine, for natural ventilation and protection against rain. A motorised option with a rain sensor is available.

Top-Hat Profiles

MiTek Top-Hat profiles are steel hat channel profiles, manufactured from galvanised steel for superior corrosion resistance. These cost effective steel battens & purlins are compatible with timber and steel trusses for either tile or metal sheeting applications

SA Roofing Advertorial

D&D Roof Insulation, specialising in roof insulation materials and thermal efficiency.

RoofSeal Datasheet | Roof Waterproofing | Cemcrete

The RoofSeal Acrylic system embraces a primer/bonding coat, an impregnating RoofSeal coat, a very tough spun bonded polyester membrane, a second impregnating RoofSeal coat and, when all work is dry (minimum 3 days), a final RoofSeal coat. RoofSeal is waterproof, very durable and ultra-violet light resistant.

Klip-Lok 700™

The profile is roll-formed from certified steel. The profile shall have 4 trapezoidal ribs at 233mm centres giving a nett cover of 700mm. The male rib shall have spurs to ensure a positive double interlocking action at side-laps. Each pan shall incorporate two stiffener ribs.

Aluminium and Canvas Awnings

Awning Warehouse’s adjustable and fixed awnings for the perfect patio solution. The range includes: aluminium sun louvres, fixed acrylic awnings, domed acrylic awnings, canvas awnings, outdoor drop blinds, retractable awnings, waterproof ceiling system, fixed patio awnings…

Reboss Awnings: DIY Awning System

A DIY awning solution, Reboss Awnings are available with either aluminium or engineered PVC brackets. Five different board finishes available – clear board, bronze tinted board, clear multiwall board, bronze tinted multiwall board, or aluminium coloured board.

Vertical and Horizontal Blinds

Awning Warehouse / Reboss Awnings’ range of vertical and horizontal blinds for solar control.

Multi Patio Structures

Multiwall Patio Structures -has the ability to reduce heat build-up, safeguard against harmful solar radiation and UV rays, and best of all, allow the sun’s natural lighrto filter through, these engineered Multiwall Polycarbonate Patio Structures are some of the strongest and most weather-resistant light transmitting building products on the market.

Retractable Patio Roofs

Our Retractable Patio Roofs effectively create shade for your outdoor spaces, and they do so much more, creating a popular space in the home morning, noon and night. Whether you are eating breakfast outside, spending time with the family in the afternoon, or hosting a party in the evening, our Retractable Patio Roofs create an ambience, turning your patio into an outdoor retreat. Our Retractable Patio Roofs are unsurpassed for style, function, simplicity, and quality – exactly what you have come to expect from Awning Warehouse. Retractable Patio Roofs are installed over decks, porches and patios in order to provide shade and protection from heat and rain. They can help to keep interior home temperatures cooler and reduce electric bills as well as keep outdoor and indoor furniture from exposure to direct sunlight.

GRS Walkways

Combining unmatched corrosion resistance with strength, long life and safety, Fiberqrate® Composite Structures Inc. sets the standard for fiberglass reinforced plastic (FRP) moulded products. Fiberqrate® products are lightweight and easy to fabricate.

Concealed Fix and Pierced Fix Profiles

Global Roofing’s range of concealed fix profile roof sheeting, including Klip-Lok, Klip-Tite, Brownbuilt and Zip-Tek. The pierced fix profiles include IBR, Nu-Rib, Corrugated, and BR7

Skylights

Aluplan is a leading manufacturer of skylights which produce a natural and elegant lighting source. Our skylight feature can offer various options from thermal protection, colour design and finish to suit virtually any natural lighting requirement.

Zip-Tek 440 Roof Sheeting

Global Roofing Solution’s Zip-Tek 440 concealed fix roofing profile.

Nu-Rib™ Profiled Sheeting

A roofing profile designed to provide the building industry with an economical alternative to the deeper Box Rib profiles without sacrificing the popular fluted concept so frequently featured in modern architecture. Nu-Rib™ is economical in comparison and is also great as a cladding option because of the shallow ribs.

IBR 890 / Supa-Clad & IBR 686

Profiled sheeting and cladding – IBR 686: The trapezoidal flute design still offers the optimum strength, mass and load-span characteristics compared to alternative profiles. IBR 890: This wide span trapezoidal profile provides the choice of a wider cover and more effective installation, saving on purlins and labour.

Zip-Tek 420 Roof Sheeting

This unique Concealed Fix system is commonly known as a standing seam system. This is one of the only Concealed Fix systems where the sheet can be tapered, as well as machine curved and reverse curved.

Improved Clips for Klip-Lok™ & Klip-Tite™

• Improved mechanical grip due to the re-development of the connector spur • Improved wind loading capabilities • Newly designed and more pronounced stiffeners have improved the rigidity in key areas

Klip-Tite™

The profile roll-formed from certified steel. The profile shall have 4 trapezoidal ribs at 233mm centres giving a nett cover of 700mm. The male rib shall have spurs to ensure a positive double interlocking action at side-laps. Each pan shall incorporate transverse stiffener ribs.

Klip-Lok 406™

The profile is roll-formed from certified steel. The profile shall have 3 trapezoidal ribs at 203mm centres giving a nett cover of 406mm. The male rib shall have spurs to ensure a positive double interlocking action at side-laps. Each pan shall incorporate two stiffener ribs.

Klip-Lok 406™ Aluminium

The profile is roll-formed from certified steel. The profile shall have 3 trapezoidal ribs at 203mm centres giving a nett cover of 406mm. The male rib shall have spurs to ensure a positive double interlocking action at side-laps. Each pan shall incorporate two stiffener ribs.

IBR 686 & 890 Supa-Clad

Pierced Fixed Sheeting

Klip-Tite - The Engineered Concealed - Fix System

Klip-Tite The Engineered Concealed Fix System

Consolidated Steel Industries - Engineered Solutions

Global Roofing Solutions (“GRS”), one of the largest metal roofing and roofing accessory manufacturers in South Africa, servicing the construction and roofing industries in South Africa and Sub-Saharan Africa; and Stalcor, one of the top three distributors of stainless steel and aluminium products in South Africa, servicing customers in the fabrication sector and steel merchants. CSI’s combining of its project-based businesses (GRS) and its trading businesses (Stalcor) has promoted synergies and created balanced revenue and cash flow streams for the group.

Corporate Profile

Global Roofing Solutions consists of two leading roofing brands, Brownbuilt Metal Sections and HH Robertson. Both these brands are household names for the manufacture of commercial and industrial steel roof coverings and wall cladding profiles (concealed fix and pierced fix), composite steel floor decking profiles and lightweight coated metal roof tiles…

Brownbuilt™ Profiled Sheeting

Brownbuilt™ is the first Concealed Fix roofing profile in South Africa and was introduced in 1964 by Brownbuilt Metal Sections. Brownbuilt™ is a concealed fix profile, with a cover width of 406mm, providing the architect with an aesthetically pleasing appearance with 90 degree standing seams, offering a watertight roofing solution.

Bond-Lok™ Composite Deck 50/270mm

Bond-Lok’s unique side lap inter-locking system provides for fast and simple construction. Bond-Lok’s spanning capabilities allow for a reduction in the number of temporary supports required. Bond-Lok eliminates the need for temporary form-work and reinforcement. Bond-Lok will accept most floor service systems. Bond-Lok’s soffit forms the finished ceiling without the need for plastering. Global Roofing Solutions has been assessed and certified as complying with ISO 9001:2015 Quality Management System. Bond-Lok has been fire-tested by the CSIR and has qualified for a fire rating of 120 minutes – results and further information are available on request.

Bond-Dek™ Composite Deck

• Bond-Dek is a composite steel flooring system for multistorey steel or concrete buildings. • Bond-Dek’s unique side-lap interlocking system provides for fast and simple construction. The speed of erection results in major labour cost savings. • Bond-Dek is able to span up to 3 metres unsupported under wet concrete with a minimum depth of 65mm over the profile. • Bond-Dek will accept most floor service systems. • Bond-Dek is available in a galvanised coated steel 0.8mm, 1.0mm and 1.2mm thick. • Bond-Dek has been fire tested by the CSIR and has qualified for a rating of 120 minutes. • Brownbuilt has been assessed and certified complying with ISO 9002 Quality Management Systems

Product Catalogue: Steel Roof Sheeting

We manufacture a complete range of roof sheets which includes Craft-Lock® and Rheefalz 38 concealed fix roofing, C-Tile®, IBR, corrugated and wide-span. We offer supporting products and services such as all types of flashings, various roofing accessories and the bull-nosing and curving of roof sheets. Full technical support such as assisting with the design of a roof, calculating quantities and taking measurements from building and construction plans is also available.

Application: Roof Tiles

Savings on your concrete formulation and manufacturing costs, Improved production output, More consistent and durable product and Superior finishes.

Starlite® Insulation

Starlite® consists of flexible rolls of insulation manufactured from high quality non-combustible glass mineral fibre using an inert thermosetting binder to form a product which is light-weight, strong, resilient, safe and highly thermally efficient. Starlite® is supplied as a plain blanket for ceiling applications, or faced with a variety of scrim re-inforced facings being aluminium foil or white coated aluminium foil for industrial and steel roof applications. Starlite® is used for thermal and acoustic applications in roofs, walls and ceilings of all types of buildings and has a working temperature of up to 230°C.

Factorylite

Factorylite is manufactured from high quality non-combustible flexible Glasswool insulation with an inert binder, which makes the product lightweight, safe and resilient. Factorylite is faced on one side with either a reinforced foil or white metalised foil. Factorylite can be faced on both sides on request.

Factoryboard

Factoryboard is a rigid board manufactured from non-combustible Glasswool insulation. Available in 25, 40 or 50 mm thickness. It can be supplied with an ASTM E-84 tested reinforced foil or white metalised foil. Alternative facings are also available (white embossed vinyl or black non-woven glass tissue).

Fascia & Barge Boards

Nutec fascia and barge boards have been designed to suit virtually any roof, whether slates, tiles or sheeting. They provide a functional finish by protecting the underlying timber structure from the elements, as well as adding visual impact to the building.

Slate Roofing

Everite, Nutec, Roofing and Cladding

The Facts about Nutec's Thermal Properties

Nutec products exhibit low thermal conductivity properties when compared with other sheet roofing and cladding products. This is ideal when reduced heat build up in summer and heat loss in winter is required.

Product Profile

Everite is renowned for its comprehensive range of Nutec Roofing and Cladding Solutions and includes fibre cement roofing, cladding, ceilings and building columns amongst others. Nutec products are distributed through leading stockists countrywide and an established export market further endorses the international acceptance of the Nutec Roofing and Cladding Solutions range of products.

Klip-Lok 700 Roofing Profile

Introduced in 1997, Klip-Lok 700™ is a Concealed Fix profile offering a wider cover width than Klip-Lok 406™, providing quicker installation. It’s manufactured in continuous lengths with on-site rolling for sheet lengths in excess of transportable limits. With the advancement in technology and the improving of products constantly happening, Klip-Tite™ has moved to replace Klip-Lok 700™. Klip-Lok 700™ will still be available for remedial work.

Putting a Roof Over Your Head

Global Roofing Solutions: Roofing & Cladding: Brownbuilt & HH Robertson Metal Roof Tiles, Roofing & Cladding Profiles, Flooring / Permanent Formwork Systems – Composite Decking

Klip-Tite Concealed Fix Roof Sheeting

New generation concealed fix roof sheeting offering superior wind uplift capabilities. Klip-Tite™ is 700mm wide, manufactured in continuous lengths with on-site rolling for sheet lengths in excess of transportable limits. Available in: Galvanised Steel, with or without a Chromadek coating, Zincalume, with or without a ColorBond coating, ZincAL, with or without ColorPlus coating…

Klip-Tite / Klip-Lok Dirt Retention - Technical Bulletin

A brief bulletin on the dirt retention of Global Roofing’s Klip-Lok and Klip-Tite concealed fixed profile roof sheets

Bond-Dek™ Composite Deck

Bond-Dek is a composite steel flooring system for multi-storey steel or concrete buildings

Steel Awards 2017

Global Roofing Solutions was proudly involved as the Roofing and Cladding manufacturer in 7 of the 8 Category Winners this year.. Congratulations to all involved in these award-winning projects.

Bond Lok™ Composite Deck

A permanent formwork/shuttering which, with concrete, acts as a composite floor slab with an attractive flat ceiling on the underside. This system significantly reduces the number of props utilized and eliminates the need for reinforcing steel.

Arma-Tile Coated Metal Roof Tiles

A strong, attractive light weight pressed metal tile with an acrylic grit finish simulating the well-known Double Roman cement tile. Its light weight significantly reduces the quantity of timber required in the support structure and provides for easy installation.

Iso-Lam Ceiling Panels

Our aesthetically pleasing product has excellent thermal insulating values, thereby creating a more comfortable environment to live and work in. These insulation properties make it ideal for insulating roofs, ceilings and walls. The additional advantage is that it provides a permanent maintenance-free internal surface

Product Information

IsoBoard thermal insulation is a high density, extruded polystyrene rigid insulation board, having a 100% closed cell structure. IsoBoard has been tried and tested internationally since 1970, and manufactured in South Africa since 1995, using a fully automated extrusion process, in  accordance with international specifications and standards.

Inverted Roof Insulation

Isoboard – the Inverted Roof Concept, also known as protected membrane or upside down roofing, ensures insulating both the water-proofing membrane and the reinforced concrete slab from extreme thermal stress. This is achieved by placing IsoBoard extruded polystyrene insulation board above, instead of below the waterproofing membrane.

Over Purlin Insulation

IsoBoard Insulation installed over purlin under roof sheet. — In South Africa, the bulk of retail and industrial buildings are steel-sheet clad frames, where 70% of the heat gain is through the roof. IsoBoard over purlin insulation is the most cost effective method of achieving thermal efficiency in these buildings.

Isoboard Physical Properties

IsoBoard, high-density extruded polystyrene rigid thermal insulation board, having 100% closed cell structure!

Under Soffit Ceilings

Where construction, design and / or cost implications prohibit the installation of an inverted roof insulation system, the requirement for insulation is met by fixing IsoBoard to the under soffit surface of the slab as a ceiling.

Sonder | Polyclosures: Eave and Ridge Fillers

Eave and ridge fillers made from cross-linked, closed cell, expanded Polyethylene. Prevents dust, draughts and birds from nesting in eaves and ridges. Waterproof, weather and UV resistant. Dust proof and extremely durable. Polyclosures are resilient and fit snugly into all types of roofing profiles.

DecoCrete | Shapeable Textured Plaster

A coloured, cement-based material formulated to be plastered to excessive thicknesses, but does not slide or shrink and dries rock hard. A textured shaping system for the creation of artistic finishes, such as rock features, imitation brick walls and pool copings.

Easy-Key

Easy-key is a universal waterproofing compound. It is a styrene/butadiene co-polymer latex that has been specifically designed for use in cement compositions.

Brochures & Datasheets
